Crane Sling Kit

The Crane Sling Kit is a professional-grade lifting solution developed for arborists performing overhead lifting and crane-supported tree removal operations. Proudly manufactured in the USA, each sling is built with MaxiBraid Plus double-braid construction, combining a 100% HMPE load-bearing core with a rugged polyester jacket for exceptional performance in demanding field conditions.

Bright green and blue bungee dock lines with hooks for securing boats, coiled and displayed side by side on a white background.
Jump To:

Crane Sling Kit

The Crane Sling Kit is a purpose-built rigging solution engineered for arborists performing tree removals and overhead lifting operations. Manufactured in the USA using MaxiBraid Plus double-braid HMPE construction, each sling features a 100% HMPE load-bearing core that delivers exceptional strength with extremely low elongation under load. The core is protected by a durable polyester cover designed to withstand repeated abrasion from rough bark, rigging hardware, and the demanding conditions encountered in arboricultural work.

To help extend service life, each sling is equipped with strategically placed chafe sleeves in high-wear areas, providing added protection against abrasion during repeated lifting, controlled lowering, and sectional dismantling operations.

Key Features

  • Designed for Arborist Lifting Applications: Engineered for tree removal and overhead lifting, delivering dependable performance in demanding arboricultural environments.
  • 100% HMPE Load-Bearing Core: High-performance HMPE fiber provides exceptional strength-to-weight ratio with extremely low elongation for improved load control.
  • Low-Stretch Performance: Minimal elongation enhances precision and stability during lifting and rigging operations.
  • MaxiBraid Plus Double-Braid Construction: Combines a high-strength HMPE core with a rugged polyester jacket for outstanding abrasion resistance and long service life.
  • Integrated Chafe Protection: Reinforced wear sleeves help protect high-contact areas from abrasion during repeated use.
  • Complete Arborist Kit: Includes two 25 ft neon green eye-and-eye slings and one 35 ft blue eye-and-eye sling, all in 5/8 in. diameter, providing versatile rigging options for a wide range of tree removal and lifting applications.

Crane Sling Kit Resources

ProductLengthWorking Load Limit *(Lbs)
Crane Sling Kit35ft (Blue); 25ft (Green)6,800
* Average break strength is based on spliced rope or capstans samples. Knots and abrupt bends significantly reduce the strength of all ropes and lower the design factor. The end user is responsible for choosing the correct design factor for their application. Angle Effect: Sling Capacities The capacity of a multiple-leg sling is directly affected by the angle of the sling leg with the vertical. As this angle increases, the stress on each leg increases. The capacity can be readily determined by multiplying the sling’s vertical capacity by the appropriate load-angle factor.
Sling Angle Vertical Load Angle Factor
0° 1.000
15° 0.966
30° 0.866
45° 0.707
60° 0.500
75° 0.259

Working Details

sling-capacities-diagrams (1)
