River Max is a double braid rope with a unique design that provides the ultimate in abrasion protection while still providing the highest strength possible, all in a High Modulus Polyethylene (HMPE) fiber construction.
The load bearing core is made of 12-strand Ultrex and provides 100% of the strength in this design. It is then over-braided and protected again by HMPE fiber, the most abrasion resistant fiber available.
Approved Splice Technique: #10015106, #10018007.
| Finished Diameter (Inches) | Core Diameter (Inches) | Weight (Lbs/100f) | Average Spliced Break Strength *(Lbs) | Minimum Spliced Break Strength *(Lbs) | Maximum Working Load 5:1 **(Lbs) |
| 5/8 | 1/2 | 9.7 | 39,250 | 35,325 | 7,850 |
| 3/4 | 9/16 | 11.9 | 47,000 | 42,300 | 9,400 |
| 7/8 | 5/8 | 17 | 55,500 | 49,950 | 11,100 |
| 1 | 3/4 | 21.6 | 75,000 | 67,500 | 15,000 |
| 1-1/8 | 7/8 | 26.6 | 98,000 | 88,200 | 19,600 |
| 1-5/16 | 1 | 35.5 | 120,000 | 108,000 | 24,000 |
| 1-3/8 | 1-1/8 | 45 | 148,000 | 133,200 | 29,600 |
| 1-1/2 | 1-1/4 | 55.4 | 172,000 | 154,800 | 34,400 |
| Finished Diameter (mm) | Core Diameter (mm) | Weight (Kg/100m) | Average Spliced Break Strength *(kg) | Minimum Spliced Break Strength *(kg) | Maximum Working Load 5:1 **(kg) |
| 16 | 13 | 14.4 | 17,815 | 16,034 | 3,563 |
| 19 | 14 | 17.7 | 21,335 | 19,202 | 4,267 |
| 22 | 16 | 25.3 | 25,195 | 22,676 | 5,039 |
| 25 | 19 | 32.2 | 34,050 | 30,645 | 6,810 |
| 29 | 22 | 39.6 | 44,490 | 40,041 | 8,898 |
| 33 | 25 | 52.9 | 54,480 | 49,032 | 10,896 |
| 35 | 29 | 67 | 67,190 | 60,471 | 13,438 |
| 38 | 32 | 82.5 | 78,085 | 70,277 | 15,617 |
* Knots and abrupt bends significantly reduce the strength of all ropes and lower the maximum working load.
** Working load is based on static or moderately dynamic lifting/pulling operations. Instantaneous changes in load, up or down, in excess of 10% of the rope’s rated working load constitute hazardous shock load and would void the normal working-load recommendation. Consult Yale Cordage for guidelines for working loads and the safe use of rope.
Specific Gravity: 0.97
Dielectric Strength: The maximum allowable leakage for clean, dry Mega Max is 75 micro-amperes when tested at 100kV per Yale Method 712-1701 Rev 1 "Routine Production Test." Absorbed and entrained moisture or impurities will increase rope’s conductivity dramatically.
