ArborMax Gator & Flame

XTC-24

ArborMax is one of our ranges of 24-carrier products is ideally suited for MRS or SRS climbing with compatible hardware or hitch tending climbing systems.

XTC-24-ArborMax-Gator-Flame-Yale-Cordage
Jump To:

XTC-24: ArborMax Gator & Flame 11.7mm

This climbing line is distributed by Bailey’s and their customers.

Innovative lightweight arborist climbing lines in 11.7mm sizing. Our range of 24-carrier products is ideally suited for MRS or SRS climbing with compatible hardware or hitch tending climbing systems.

Key Features

  • Competition grade
  • Smoothest cover for mechanical ascension
  • Perfect balance of strength & low elongation
  • Smaller diameters are also favorable for recreational climbers
  • ANSI Z133 100% polyester climbing lines

This standard (NON CE) version offers lower elongation for a climber who prefers less bounce in either their SRS of MRS systems.

XTC-24 ArborMax Specifications and Data

Product (Text) Diameter (mm) Average Break Strength *(Lbs) Suggested Design Factor 10:1 **(Lbs) Weight (Lbs/100f)
ArborMax 11.7 6,500 650 6.5
* Average break strength is based on spliced rope or capstans samples. Knots and abrupt bends significantly reduce the strength of all ropes and lower the design factor. ** Suggested design factor is based on static or moderately dynamic lifting/pulling operations. Instantaneous changes in load, up or down, in excess of 10% of the rope’s suggested design factor constitute hazardous shock load and would void the suggested design factor recommendation. The end user is responsible for choosing the correct design factor specific to their application.
Product (Text) Diameter (mm) Average Break Strength *(kg) Suggested Design Factor 10:1 **(kg) Weight (Kg/100m)
ArborMax 11.7 2,948 295 9.7
* Average break strength is based on spliced rope or capstans samples. Knots and abrupt bends significantly reduce the strength of all ropes and lower the design factor. ** Suggested design factor is based on static or moderately dynamic lifting/pulling operations. Instantaneous changes in load, up or down, in excess of 10% of the rope’s suggested design factor constitute hazardous shock load and would void the suggested design factor recommendation. The end user is responsible for choosing the correct design factor specific to their application.

Working Details

Green working 263 ft. lbs./lb.

Red ultimate 7,050 ft. lbs./lb.

Specific Gravity

1.38

RopeCharts.XTC24.v1
