R.I.N.G. Rope
XTC-48
XTC-48 RING is a high performance climbing line with a light weight design featuring an exclusive, ultra-smooth 48-carrier cover.
Jump To:
XTC-48: R.I.N.G. Rope 10.5mm & 11.5mm
High performance climbing line with a light weight design featuring an exclusive, ultra-smooth 48-carrier cover. Ideally suited for mechanical climbing systems used in competitive tree climbing.
- EN 359 certification for ultra-durable heat-resistant lanyards
- Utilize for utra-static access line for long climbs or situations where cut resistance is of utmost importance
- Exclusive tri-braid design with red inspection layer, where if the cover is damaged Red – Is – No – Go
XTC-48 R.I.N.G. Rope Specifications and Data
| Diameter (mm) | Average Break Strength *(Lbs) | Working Load Limit at 10:1 Design Factor (lbs) | Weight (Lbs/100ft) |
|---|---|---|---|
| 11.5 | 6,500 | 650 | 6.2 |
| 10.5 | 5,300 | 530 | 5.5 |
| Diameter (mm) | Average Break Strength *(kg) | Working Load Limit at 10:1 Design Factor (kg) | Weight (Kg/100m) |
|---|---|---|---|
| 11.5 | 2,900 | 290 | 9.2 |
| 10.5 | 2,400 | 240 | 8.2 |
Working Details
Green working 155 ft. lbs./lb.
Red ultimate 9,775 ft. lbs./lb.
Specific Gravity
1.23
Dielectric Strength
The maximum allowable leakage for clean, dry Kernmaster is 500 micro- amperes when tested at 100kV per Yale Method 712-1701 Rev 1 “Routine Production Test.” Absorbed and entrained moisture or impurities will increase rope’s conductivity dramatically.
